Reverse Jet BagFilter 4T
OPTIMAL SOLUTIONS FOR AIR ENVIRONMENTAL
CONTROL
CHARACTERISTICS
The SimPact 4T filter is characterised by a cylindrical design and an efficient pulse-jet system, automatically cleaning the filter bags in rows during operation.
The SimPact 4T pulse-jet filter is designed for continuous operation with a low pressure drop and has excellent features for separation of dry, as well as sticky dust particles.
■ Efficient pulse-jet cleaning.
■ Up to 50 % vacuum resistance.
■ Maintenance-free execution.
■ Side or top removal of filter bags.
■ Available in sanitary design.
■ Control system saving compressed air.
■ Advanced control functions.
■ Separation of almost any type of dust.
APPLICATIONS
■ Building materials industry.
■ Chemical industry.
■ Plastics industry.
■ Food processing industry.
■ Feedstuffs industry.
■ Wood and paper industry.
■ Foundries.
■ Incineration industry.
■ Minerals industry.
■ Textiles industry.
■ Colour and enamel industry.
APPROVAL BY TUV
Due to increasing demand for protection of pulse-jet filters against explosions, AIR PROCESS SOLUTIONS/ Simatek’s filter programme has been tested and approved by TÜV Nord e.V., one of the world’s leading institutions for approval of safety equipment.
Filters are both pressure and shock resistant according to German guidelines VDI 2263. Each filter unit can be supplied with an acceptance
declaration, ensuring approval by local authorities.
AIR PROCESS SOLUTIONS / SIMATEK REVERSE-JET BAG FILTERS 4T
AIR PROCESS SOLUTIONS/ Simatek Low Pressure Reverse Pulse Bag Filters enable economic collection of fumes and dust at high filtration rates, utilising absorption techniques to remove acid gases, heavy metals and dioxins from flue gases.
The SimPact 4T filter is an economic solution for dust collection in industrial plants, with the investment often paid back in terms of product
DESIGN
The SimPact 4T filter is designed to operate with dust explosion vents, as stipulated in the German VDI 3673 guidelines. Design of the filter housing and the inlet zone ensures a smooth flow of coarse particles as well as fine dust particles into the filter.
The 4T concept of combining the ideal filter unit with any of the five inlet designs, renders the solution suitable to almost any separation.
